9BB Half-Cell 410Wp Mono Solar Module
Assembled with multi-busbar PERC cells, the half-cell configuration of the modules offers the advantages of higher power output, better temperature-dependent performance, reduced shading effect on the energy generation, lower risk of hot spot, as well as enhanced tolerance for mechanical loading.

Online service
Online inquiries

 Detailed
【Product introduction】



Cell Mono
No. of cells 144(6×24)
Rated Maximum Power(Pmax) 410W
Maximum Efficiency 20.36%
Junction Box IP68
Maximum System Voltage 1000V/1500V DC
Operating Temperature -40℃~+85℃

Benefits:

  • Higher output power
  • Lower LCOE
  • Less shading and lower resistive loss
  • Better mechanical loading tolerance


Product Characteristics

Model No.
HCM72X9-395 HCM72X9-400 HCM72X9-405 HM72X9-410
Warranty
Product Warranty 10 Years
Power Warranty 12 Years of 90% Output Power, 25 Years of 80% Output Power
Electrical Data at STC
Maximum Power (Pmax)
395 Wp 400 Wp 405 Wp 410 Wp
Voltage at Maximum Power (Vmpp)
41.5 V 41.8 V 42.1 V 42.3 V
Current at Maximum Power (Impp)
9.52 A 9.57 A 9.62 A 9.7 A
Open Circuit Voltage (Voc)
49.4 V 49.6 V 49.8 V 50 V
Short Circuit Current (Isc)
10.12 A 10.16 A 10.21 A 10.25 A
Panel Efficiency
19.62 % 19.87 % 20.11 % 20.36 %
Power Tolerance (Positive)
+ 1 % + 1 % + 1 % + 1 %
  Standard Test Conditions (STC): air mass AM 1.5, irradiance 1000W/m2, cell temperature 25°C
Electrical Data at NOCT
Maximum Power (Pmax)
298 Wp 302 Wp 305 Wp 309 Wp
Voltage at Maximum Power (Vmpp)
39.3 V 39.6 V 39.9 V 40.2 V
Current at Maximum Power (Impp)
7.57 A 7.62 A 7.65 A 7.69 A
Open Circuit Voltage (Voc)
47.1 V 47.3 V 47.5 V 47.7 V
Short Circuit Current (Isc)
8.16 A 8.19 A 8.23 A 8.27 A
Temperature
45±2 °C 45±2 °C 45±2 °C 45±2 °C
  Nominal Operating Cell Temperature (NOCT): 800W/m2, AM 1.5, windspeed 1m/s,ambient temperature 20°C
Thermal Ratings
Operating Temperature Range -40~85 °C
Temperature Coefficient of Pmax -0.37 %/°C
Temperature Coefficient of Voc -0.29 %/°C
Temperature Coefficient of Isc 0.05 %/°C
Maximum Ratings
Maximum System Voltage 1000 V
Series Fuse Rating 20 A
Material Data
Panel Dimension (H/W/D) 2010x1002x40 mm
Weight 23 kg
Cell Type Monocrystalline
Cell Size 158.75×158.75 mm
Cell Number 144
Glass Type TCO, Tempered, Anti-reflection Coating, High Transmittance
Glass Thickness 3.2 mm
Encapsulant Type EVA
Frame Type Anodized Aluminium Alloy
Junction Box Diodes 3
Junction Box Protection Class IP 68
Connector Type MC4
Cable Crossection 4 mm2
